| Mount Type | Fixed Landscape Wall Mount |
|---|---|
| Mounting Pattern | Universal |
| Material | Steel |
| Recommended Screen Size | 50"-100" |
| Weight Capacity | 100kg/220lbs |
| Load Tested | 4 times weight capacity approved |
| Maximum Hole Pattern (WxH) | 923x610mm |
| Compatible VESA Patterns | 200x200, 400x200, 300x300, 400x400, 600x400, 800x400, 900X600 |
| Maximum VESA Pattern | 900x600 |
| Tilt | 0° |
| Swivel | 0° | Level Adjustment | 0° |
| Rotation | 0° |
| Profile | 32mm |
Technical Drawing - Low-Profile Landscape Wall Mount (Max. VESA 900x600) - AS3769F
CAD Drawing - Low-Profile Landscape Wall Mount (Max. VESA 900x600) - AS3769F Data Sheet - Low-Profile Landscape Wall Mount (Max. VESA 900x600) - AS3769F Installation Guide - Low-Profile Landscape Wall Mount (Max. VESA 900x600) - AS3769F
